Custom PCB Service
OEM Customised PCB Process
Step 1 Remarks
Customer data usually include gerber, and technical information such as board thickness / copper thickness / surface / solder mask color / silkscreen color / impedance / special requirement, etc.
Step 2 Check data
Factory engineer will check customer data carefully, and provide EQ (engineering query) to customer to get confirmation if have any doubt about PCB design or requirement.
Step 3 Get EQ answer
When we get EQ answer from customer,we will edit internal manufacture instruction (MI) and working gerber (used for films fabrication,such as copper layers / solder mask layers / silkscreen layers / drilling layer / outline layer,etc.)
Step 4 Start production
Start production, take HDI and Aluminum PCB as example, processes as follows.
Step 5 We do FAI report
We do FAI report, packing with PCBs together, and then send to customer. Shipment by different ways,such as DHL, Fedex, UPS, TNT and so on.
